KOMADA Fully Powered Hand Pallet Truck
KOMADA Fully Powered Hand Pallet Truck
KOMADA FF15-E brings maximum flexibility in configurations for every application. The standard single 24V/20Ah battery setting comes with a portable storage container to keep everything easily accessible on the go. Its versatilty makes FF15-E an all rounder, perfect for diverse tasks in the most cost effective way.
Specifications :
| Product Code | FF15-E | ||||
| Drive Type | Electric | ||||
| Operation Type | Pedestrian | ||||
| Rated capacity (Q) | kg | 1500 | |||
| Load centre distance (c) | mm | 600 | |||
| Load distance, centre of drive axle to fork (x) | mm | 950 | |||
| Wheel Based (y) | mm | 1180 | |||
| Service Weight | |||||
| Service weight (include battery) | kg | 120 | |||
| Axle loading, laden front / rear | kg | 480 / 1140 | |||
| Axle loading, unladen front / rear | kg | 90 / 30 | |||
| Tyres Chassis | |||||
| Tyre type | Polyurethane | ||||
| Tyre size, front | mm | 210 x 70 | |||
| Tyre size, rear | mm | 80 x 60 | |||
| Additional wheel (castor wheels) | mm | 74 x 30 | |||
| Wheels, number front / rear (x=drive wheels) | mm |
1x , -/4 |
|||
| Tread width, front (b10) | mm | - | |||
| Tread width, rear (b11) | mm |
410 (535)
|
|||
| Dimensions | |||||
| Fork dimension | mm | 1150 x 685 | |||
| Fork lowered height | mm | 80 | |||
| Drive Cover off the ground | mm | 55 | |||
| Lift Height (h3) | mm | 105 | |||
| Height of tiller handle in drive position min./max | mm | 750 /1190 | |||
| Lowered height (h13) | mm | 88 | |||
| Overall length (l1) | mm | 1550 | |||
| Length to face of forks (l2) | mm | 400 | |||
| Overall width (b1/b2) | mm | 590 (695) | |||
| Fork dimensions (s/ e/ l) | mm |
55 / 150 / 1150 |
|||
| Distance between fork arms (b5) | mm | 560 (685) | |||
| Ground clearance, center of wheelbase (m2) | mm | 25 | |||
| Aisle width for pallets 1000 x 1200 crossways (Ast) | mm | 2160 | |||
| Aisle width for pallets 800 x 1200 lengthways (Ast) | mm | 2025 | |||
| Turning radius (Wa) | mm | 1360 | |||
| Performance Data | |||||
| Travel speed, laden / unladen | km/h | 4/4.5 | |||
| Lifting speed, laden / unladen | m/s | 0.017 / 0.020 | |||
| Lowering speed, laden / unladen | m/s | 0.058 / 0.046 | |||
| Max. gradeability, laden/ unladen | % | 6/16 | |||
| Service brake | Electromagnetic | ||||
| Electric-Engine | |||||
| Drive motor rating S2 60 min | kW | 0.75 | |||
| Lift motor rating at S3 15% | kW | 0.5 | |||
| Battery voltage/nominal capcity | V/Ah | 24 / 20 | |||
| Battery weight | kg | 5 | |||
| Energy consumption according to DIN EN 16796 | kWh/h | 0.18 | |||
| Turnover output according to VDI 2198 | t/h | 60 | |||
| Turnover efficiency according to VDI 2198 | t/kWh | 333.33 | |||
| Addition Data | |||||
| Type of drive control | DC | ||||
| Steering design | Mechanical | ||||
| Sound pressure level at the driver's ear | dB (A) | 74 | |||
| Load Wheel Material | PU | ||||
| Drive Wheel Material | PU | ||||
| Battery Capacity | 20 Ah x 1 , portable storage box | ||||
| Battery Indicator | Without time | ||||
